FLYING LEADS
Turnkey flying lead solutions engineered for reduced operational risk and third party costs.
Reduced vessel time through easy, safe and reliable operations.
FEATURES
- Designed to handle thermoplastic hose and steel tube
- Thermoplastic hose available with high collapse resistance
- Helicoil and loose-lay HFL/HSL systems
- Spiral wrapping and extruded outer sheath as specified
- Secondary release mechanism for emergency override
SPECIFICATIONS
- Working pressure: up to 15 000 psi
- Hose sizes: ¼ to 1″
- Operating temperature: -18 to +121 °C
- Maximum water depth: 3 030 m
- Design/qualification codes: API 70E, ISO 13628-5-2009
Solution applications
- Umbilical Termination Units
- Subsea Distribution Units
- Subsea Trees
- Subsea Manifolds
